Welding Rod
- 0 Views
Introduction: E6013 is a low fume, high titania type electrode, whose usability is excellent in all position welding. This electrode is suitable for the welding of small thin pipe. It is also suitable for vertical downward welding.
Application: E6013 can be used for welding of mild steel sheet, structures in ships, railway vehicles, cars and other machineries, surface dressing of heavy steel structures.
Typical chemical composition of weld metal (%)
C | Mn | Si | S | P |
0.08 | 0.40 | 0.25 | 0.011 | 0.014 |
Typical mechanical properties of weld metal:
Y.S MPa | T.S MPa | EL. (%) | Temp ℃ | CVN. Impact value J |
420 | 500 | 25 | 0 | 73 |
Approval: ABS, LR, GL.DNV, CCS
Packing: 5kg(11 lbs)/box, 5kg(11 lbs) x 4box: 20kg(44 lbs)/carton
Recommended currents (Amp.):
Size (mm) | 2.5 | 3.2 | 4.0 | 5.0 |
Length(mm) | 350 | 350 | 400 | 400 |
Current(A) | 60-90 | 90-130 | 140-190 | 190-240 |
Notes on Usage:
1. Dry the electrodes at 70-100℃ for 30-60 minutes before use if necessary.
2. Pay attention not to exceed the range of proper currents.
3. In case of vertical downward welding, manipulate the electrode, keeping its tip in contact with base metal.
WELDING POSITION:
